Double Sliding Door System-858

Double Sliding Door System (858) is a sliding shower door system for standing showers and bathtub screens, built from 304 stainless steel.

✓ IN STOCK
Get A Quote

Send Inquiry

Please fill out the form below, we will quote you soon.

SHARE

This sliding door system is designed for full standing showers or above bathtubs.

It can accommodate a wide range of shower design with fixed glass panel on either end, or both sides at 180 degree.

The shower room is available in various width specifications.

System Specification — Double Sliding Door System 858

The 858 is the series’ dedicated 180° double-sliding configuration: two moving leaves glide on a shared track, opening the full door width without swinging leaves into the room. It accepts 10 mm tempered glass per leaf, with stainless roller assemblies riding an anodized aluminum track that keeps the glide quiet at full speed. The system suits openings where a single slider would leave half the width blocked — wide shower openings, walk-through enclosures and corner layouts that feed a return panel.

Parameter 858 specification Selection note
Glass 10 mm tempered, 2 leaves Match thickness across all panels
Configuration 180° double sliding Corner variants on the 808
Track Anodized aluminum 304 stainless track option
Rollers Stainless, sealed bearings Sealed bearings keep water out
Leaf weight limit 40 kg per leaf Weigh glass before ordering

Buyers comparing configurations across the series — single slider on the 809, corner layouts on the 808, full-width double sliding on the 889 — can map the trade-offs in the sliding shower door system selection guide, and the sealing components that complete the 858 are covered in the shower door seals specification guide. Finish selection follows the hardware program: PVD over stainless for humid-year stability, anodized tones for colour depth.

Key Features

  • Material: 304 stainless steel construction

Applications

  • Sliding doors over bathtubs in family bathrooms
  • Full standing shower enclosures in hotels and apartments
  • Straight-run layouts with fixed panels at one or both ends
  • 90° and 180° corner shower configurations
  • Projects needing a cut-to-size header for non-standard openings
  • Wholesale and OEM sourcing programs – a recurring anodized aluminum shower track line for distributors

More in this series: Double Sliding Door System-865 · Double Sliding Door System-855

Installation Notes

  1. Fit the header rail and cut its 72″ (1830 mm) width to the opening on site.
  2. Mount the rollers on the door leaf – total glass weight must stay under 88 lb (40 kg).
  3. Hang the door, set the floor guides for the fixed panels, and adjust roller height for even gaps.
  4. Install stoppers and check the full travel of the door before sealing.
  5. Two-person installation recommended – full glass sheets are heavy.

Frequently Asked Questions

What is the 858 made of?

The 858 is built from 304 stainless steel. Solid metal construction matters on glass hardware – thin stamped parts creep loose under door loads.

What opening width does the sliding system cover?

The header ships at 72″ (1830 mm) and is cut down on site to the real opening; leaf weight stays under 88 lb (40 kg) with fixed panels at one or both ends.

What maintenance does a sliding system need?

Keep the top track clear of debris and check roller tension yearly. The wheels carry the door weight, so a clean track does more than any lubricant.

Do you supply the stainless shower door rollers for wholesale and OEM programs?

Yes – this model is produced in Zimmor’s Foshan factory for wholesale and OEM sourcing: custom finishes, packaging and volume pricing are confirmed per order.
