90 Degree Corner Bracket Shower Support Bar Accessories-5515-90
90 Degree Corner Bracket Shower Support Bar Accessories (Z-5515-90) is a shower support bar & bracket series that stiffens fixed frameless panels against lateral movement, built from brass.
90 Deg Corner Bracket for Support Bars
The 90 Degree Corner Bracket Shower Support Bar Accessories 5515 90 is a shower support bar accessory that stabilises frameless glass panels against lateral movement: bar-to-glass and bar-to-wall interfaces machined to clamp without crushing, finish-matched to the bathroom’s hardware program, and engineered so lateral loads travel into the wall — not into the panel’s set screws.
| Specification | Standard | Selection note |
|---|---|---|
| Interface | Bar-to-glass + bar-to-wall variants | Match to support bar profile |
| Material | Brass core, plated finish | PVD option for humid years |
| Glass thickness | 8–12 mm clamp range | Measure panel before ordering |
| Finish | Chrome / brushed nickel / matte black | Match room hardware set |
The support bar specification that pairs with these accessories — tubing, finishes and load paths — is detailed in the support bar specification guide. Reference: shower construction.
Key Features
- Material: brass construction
- Geometry: built for 90° panel angles
Applications
- Stabilizing fixed glass panels in walk-in showers
- Wall-to-glass and glass-to-glass bracing in frameless enclosures
- Supporting tall panels where a header is not wanted
- Corner and T-junction layouts needing angled brackets
- Renovation jobs where the existing panel has started to wobble
- Wholesale and OEM sourcing programs – a recurring frameless glass support line for distributors
More in this series: Vertical Bracket Shower Support Bar Accessories-5533 · Movable Bracket Shower Support Bar Accessories-5534
Installation Notes
- Install the fixed panel first and confirm it is plumb.
- Mark the bar position on wall and glass, then fit the wall bracket with suitable anchors.
- Clamp the bar to the glass with the rubber-lined glass bracket – snug, not crushing.
- Adjust length/angle (where the model allows) so the load reads into the wall, not the set screws.
- Professional installation recommended for panels above head height.
Frequently Asked Questions
What is the Z-5515-90 made of?
The Z-5515-90 is built from brass. Solid metal construction matters on glass hardware – thin stamped parts creep loose under door loads.
How strong is a support bar connection?
The bar does not carry gravity – the panel stands on its own – but it must resist lateral push. That is why the wall side anchors into structure and the glass side clamps with rubber-lined brackets, keeping the temper intact.
Can the brackets be repositioned after fitting?
Movable and swiveling types slide or rotate on the bar, so small corrections are easy. Fixed-angle brackets should be re-drilled rather than forced.
Do you supply the frameless glass support for wholesale and OEM programs?
Yes – this model is produced in Zimmor’s Foshan factory for wholesale and OEM sourcing: custom finishes, packaging and volume pricing are confirmed per order.
